Part Number: 9680149 / Vendor ID Number: 1152311 / Custom:
18" Deluxe Gear Head Milling Machine

18" Deluxe Gear Head Milling Machine
by C.H. Hanson

13,700
23
Pack Of: 1
Contact for Availability
Add To Cart
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Overview
The all gear drive transmission delivers full power at any speed driving the cutting tools at nearly 100% of the available motor horsepower and torque. This Palmgren mill comes as a complete deluxe package with machine, storage cabinet, DRO, spindle, head and table power feed, tool storage, and numerous digital readouts. Equipped with a high performance brushless DC motor with permanent current control and the latest technology variable speed inverter. This all-purpose mill is ideal for milling, drilling, slotting, engraving, boring, tapping and angle machining operations in all types and sizes of shops.
Product Availability
Technical Details
Details
Brand:
Palmgren
Catalog Product Features:
• Automatic tapping cycle
Catalog Product Features-2:
• Heavy duty steel floor stand cabinet with easy access door and drawer for added storage and stability
Catalog Product Features-3:
• Precision ground t-slotted cross slide table with adjustable limit stops, large hand wheels and “X” axis table power feed Head angles up to 45 degrees and comes with a LED tilting angle display
Catalog Product Features-4:
• R-8 spindle tooling storage tray mounted to the side of the machine for easy access. Work light
Catalog Product Features-5:
• Rigid box column with hardened, ground and hand-scrapped dovetail ways provide accurate head positioning with minimum deflection. Power “Z” axis head position. Precision machine tool R-8 spindle with taper roller bearings and spindle concentricity
Catalog Product Features-6:
• Spindle safety guard. Draw bar and way covers
Catalog Product Features-7:
• Variable speed with digital spindle speed display. Digital depth gauge display. Manual dial fine feed mechanism for accurate down feed movement of the spindle. 3 Axis DRO with reference point, calculator, absolute/incremental operation, conversion inch
Country of Origin:
CHINA
Drilling Capacity:
1.18”
End Mill Capacity:
1.”
Face Milling Capacity:
2.5”
Freight Class:
110
Head Tilt:
+/- 45°
HP:
1-1/2 HP
Max. Distance Spindle To Table:
13-3/8"”
Overall Dimensions (LxWxH):
37-1/2" x 30-1/3" x 68-3/4"
Phase:
1 PH
Product Features:
Rigid box column with hardened, ground and hand-scrapped dovetail ways provide accurate head positioning with minimum deflection. Power “Z” axis head position. Precision machine tool R-8 spindle with taper roller bearings and spindle concentricity of
Retail Height (inches):
45.5
Retail Length (inches):
65.4
Retail Weight (lbs):
651
Retail Width (inches):
33
Spindle Speed:
100-5000RPM
Spindle Taper:
R8
Status:
A
T-slot size:
12 mm
Table Effective Size:
7” x 29”
Tapping Capacity:
1/2”
Throat:
9”
UPC:
7.26897E+11
Voltage:
115V
X Axis Travel:
19.75”
Y Axis Travel:
8.25”
Z-Axis Travel:
10”
Manufactured By:
C.H. Hanson
